Marca:
MSI
Modelo:
PRO H510M-B II
Chipset:
INTEL H470
CPU:
2x DDR4, Maximum Memory Capacity 64GB
Memory Support 2933/ 2666/ 2400/ 2133 MHz
Supports 1R 2133/ 2666/ 2933 MHz for Intel Core™ i9/ Core™ i7 CPU
Supports 1R 2133/ 2666 MHz for Intel® Core™ i5/ Core™ i3/ Pentium® Gold and Celeron® CPU
Supports Dual-Channel mode
Supports non-ECC, un-buffered memory
Supports Intel® Extreme Memory Profile (XMP)
Onboard Graphics:
1x HDMI™
Support HDMI™ 1.4, maximum resolution of 4K 30Hz*
1x VGA
Support VGA, maximum resolution of 2048x1536 50Hz, 1920x1200 60Hz
Slot:
1x PCI-E x16 slot
1x PCI-E x1 slot
PCI_E1 Gen PCIe 3.0 supports up to x16 (From CPU)
PCI_E2 Gen PCIe 3.0 supports up to x1 (From Chipset)
Storage:
1x M.2
M.2_1 Source (From Chipset) supports up to PCIe 3.0 x4 / SATA mode, supports 2280/2260/2242 devices
4x SATA 6G
USB:
4x USB 2.0 (traseira)
4x USB 2.0 (frontal)
2x USB 5Gbps Tipo A (traseira)
2x USB 5Gbps Tipo A (frontal)
LAN:
Realtek® 8111H Gigabit LAN
Audio:
Realtek ALC897 Codec
7.1-Channel High Definition Audio
Internal Io:
1x Conector de alimentação (ATX_PWR)
1x Conector de alimentação (CPU_PWR)
1x Ventoinha da CPU
2x Ventoinha do sistema
2x Painel frontal (JFP)
1x Intrusão do chassi (JCI)
1x Áudio frontal (JAUD)
1x Porta COM (JCOM)
1x Conector LED RGB (JRGB)
1x Cabeçalho de pino TPM (suporte TPM 2.0)
4x Portas USB 2.0
4x Portas USB 5Gbps Tipo A
Fator de Forma:
mATX
202 mm x 236 mm
Garantia de 180 dias
