| EAN |
7898722600638 |
| CPU |
Supports 6/7th (SKYlake). Intel 14nm CPUs |
|
|
| Chipset |
Intel H110 Express Chipset |
|
|
| Memory |
2 x 240-pin DDR4 SDRAM slots |
|
Memory up to 32GB |
|
Supports dual channel DDR4 2133/2400/2666 MHZ |
|
|
| I/O Interface |
4 x USB, compatible with USB2.0 |
|
2 x USB, compatible with USB3.0 |
|
1 x VGA port |
|
1 x HDMI port |
|
1 x RJ45 port |
|
1 x 3-in-1 Audio port (line In/Line Out/MIC IN) |
|
|
| Onboard Interface |
1 x 24-pin ATX power connector |
|
1 x 4-pin ATX 12V power connector |
|
1 x USB2.0 connector, can support 2*USB 2.0 |
|
1 x USB3.0 connector, can support 2*USB 3.0 |
|
1 x F_AUDIO connector |
|
1 x F_PANEL connector |
|
1 x SPEAKER connector |
|
2 x FAN connector |
|
4 x serial SATA/6GB/S connector port |
|
1 x LPC_DEBUG connector |
|
|
| Integrated sound |
with 6-channel HD Audio Codec onboard |
|
provides front audio interface; |
|
provides front stereo mic interface |
|
|
| Integrated Lan |
with 10/100/1000Mbps LAN onboard |
|
|
| Expansion Slot |
1 x PCI Express x16 slot |
|
1 x NVMe M.2 connector |
|
|
| Dimension |
Micro-ATX architecture (17*19cm) |
